C Type Stainless Steel U Section Channel 0.2mm 0.3mm 0.4mm
Product Details:
| Place of Origin: | Jiangsu, China |
| Brand Name: | Tisco Technology |
| Certification: | ISO9001 |
| Model Number: | Tisco - 7 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1-18 Tons |
|---|---|
| Price: | $1,300.00/Tons |
| Packaging Details: | Industry seaworthy wooden package or as customer's requirements |
| Delivery Time: | 7-15 work days |
| Supply Ability: | 5000 Ton/Tons per Month |
|
Detail Information |
|||
| Product Name: | Stainless Steel Profile | Surface: | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
|---|---|---|---|
| Payment Term: | L/C T/T (30% Deposit) | Technique: | Cold Rolled Hot Rolled |
| Standard: | GB JIS EN ASTM, AiSi, ASTM, Bs, DIN, GB, JIS | Grade: | 201,304,309,316,316L,321,410,430,904, 200 Series,300 Serie |
| Shape: | U Channel/C Channel | Perforated Or Not: | Not Perforated, Not Perforated |
| Processing Service: | Bending, Welding, Punching, Decoiling, Cutting | Surface Treatment: | Clean, Blasting And Painting |
| High Light: | C Type stainless steel u section channel,stainless steel u section channel 0.2mm,0.4mm brushed stainless steel u channel |
||
Product Description
Factory direct sell 321 904 stainless steel u channel c channel profile
|
Stainless Steel |
ASTM |
201, 202, 301, 304, 304L, 304N, XM21, 304LN, 305, 309S, 310S, 316, 316Ti, 316L, 316N, 316LN, 317, 317L, 321, 347, 329,
405, 409, 430, 434, 444, 403, 410, 420, 440A, etc. |
|
EN |
1.4372, 1.4373, 1.4319, 1.4301, 1.4306, 1.4315, 1.4303, 1.4833, 1.4845, 1.4401, 1.4571, 1.4404, 1.4429, 1.4438, 1.4541, 1.4550,
1.4477, 1.4462, 1.4002, 1.4512, 1.4016, 1.4113, 1.4509, 1.4521, 1.4006, 1.4021, 1.4028, etc. |
|
|
JIS |
SUS201, SUS202, SUS301, SUS304, SUS304L, SUS304N1, SUS304N2, SUS304LN, SUS305, SUS309S, SUS310S, SUS316, SUS316L, SUS316TI,
SUS316N, SUS316LN, SUS316J1, SUS316J1L, SUS317, SUS317L, SUS321, SUS347, SUS329J1, SUS329J3L, SUS405, SUH409, SUS410L, SUS430, SUS434, SUS444, SUS403, SUS410, SUS420J1, SUS420J2, SUS440A, SUS440B, SUS440C, etc. |
Our product process can adjust as your needed standard such as AISI, ASTM, DIN, GB etc with professional dection export.We also provide different materials for stainless steel including 200 series, 300 series, 400 series. You can choose your products as you need.
|
Name
|
Stainless steel pipe,201stainless steel,304 stainless steel,316 stainless steel
|
|
Certificate
|
SGS,ISO,BV
|
|
Surface
|
2B,BA(bright annealed) NO.1 NO.2 NO.3 NO.4,8K HL(Hair Line) PVC
|
|
Thickness
|
0.2/0.3/0.4/0.5/0.6/0.7/0.8/0.9/1/2/3/4/5/6/7/8/9mm...
|
|
Width
|
10/20/30/40/50/60/70/80/90/100/200/300/400/500/600/700/800mm..
|
|
Length
|
1/2/3/4/5/6/7/8/9/10/20/30/40/50m...
|
|
Grade
|
201/202/303/304/304ji/304L/309s/310s/316/316L/316Ti/409/410/430/904L.etc
|
|
Delivery
|
15-20 days after the deposit or LC.
|
|
Payment
|
T/T, Western union, Paypal.etc
|
|
Sample
|
Free samples always but freight should be collected at your side.
|
|
|
Stable quality with reasonable price.
|
|
Good shaping capability,weld bending capability,high thermal conductivity,low thermal expansion with our 7x24 after-sales service
|
|
|
Shipment
|
Three days for samples and 7 days for batch production.
|
|
Product Name
|
Hot Rolled Stainless Steel U Channel
|
|
Type
|
U Shape
|
|
Size
|
40*20 --- 200*100
|
|
Thickness
|
4-10 mm
|
|
Length
|
1000-6000 mm
|
|
Surface Finish
|
NO.1
|
|
Grade
|
201, 304, 304S, 316, 316L etc.
|
|
Standard
|
ASME, ASTM, EN, BS, GB, DIN, JIS etc
|
Specification Details
|
Sectional Dimension
|
Kg/m
|
Sectional Dimension
|
Kg/m
|
|
100*50*5*7
|
9.54
|
344*354*16*16
|
131
|
|
100*100*6*8
|
17.2
|
346*174*6*9
|
41.8
|
|
125*60*6*8
|
13.3
|
350*175*7*11
|
50
|
|
125*125*6.5*9
|
23.8
|
344*348*10*16
|
115
|
|
148*100*6*9
|
21.4
|
350*350*12*19
|
137
|
|
150*75*5*7
|
14.3
|
388*402*15*15
|
141
|
|
150*150*7*10
|
31.9
|
390*300*10*16
|
107
|
|
175*90*5*8
|
18.2
|
394*398*11*18
|
147
|
|
175*175*7.5*11
|
40.3
|
400*150*8*13
|
55.8
|
|
194*150*6*9
|
31.2
|
396*199*7*11
|
56.7
|
|
198*99*4.5*7
|
18.5
|
400*200*8*13
|
66
|
|
200*100*5.5*8
|
21.7
|
400*400*13*21
|
172
|
|
200*200*8*12
|
50.5
|
400*408*21*21
|
197
|
|
200*204*12*12
|
72.28
|
414*405*18*28
|
233
|
|
244*175*7*11
|
44.1
|
440*300*11*18
|
124
|
|
244*252*11*11
|
64.4
|
446*199*7*11
|
66.7
|
|
248*124*5*8
|
25.8
|
450*200*9*14
|
76.5
|
|
250*125*6*9
|
29.7
|
482*300*11*15
|
115
|
|
250*250*9*14
|
72.4
|
488*300*11*18
|
129
|
|
250*255*14*14
|
82.2
|
496*199*9*14
|
79.5
|
|
294*200*8*12
|
57.3
|
500*200*10*16
|
89.6
|
|
300*150*6.5*9
|
37.3
|
582*300*12*17
|
137
|
|
294*302*12*12
|
85
|
588*300*12*20
|
151
|
|
300*300*10*15
|
94.5
|
596*199*10*15
|
95.1
|
|
300*305*15*15
|
106
|
600*200*11*17
|
106
|
|
338*351*13*13
|
106
|
700*300*13*24
|
185
|
Chemical Composition
|
Grade
|
Chemical Composition (%)
|
Mechanical Performance
|
|||||||
|
|
C
|
Si
|
Mn
|
P
|
S
|
Ni
|
Cr
|
Mo
|
Hardness
|
|
201
|
≤0.15
|
≤1.00
|
5.5/7.5
|
≤0.060
|
≤0.03
|
3.5/5.5
|
16.0/18.0
|
-
|
HB≤241,HRB≤100, HV≤240
|
|
304
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
8.0/11.0
|
18.00/20.00
|
-
|
HB≤187,HRB≤90,HV≤200
|
|
316
|
≤0.08
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10.00/14.00
|
16.0/18.0
|
2.00/3.0
|
HB≤187, HRB≤90 HV≤200
|
|
316L
|
≤0.03
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.03
|
10.00/14.00
|
16.0/18.0
|
2.00/3.0
|
HB≤187, HRB≤90 HV≤200
|
|
410
|
≤0.15
|
≤1.00
|
≤1.25
|
≤0.060
|
≤0.03
|
≤0.060
|
11.5/13.5
|
-
|
HB≤183, HRB≤88 HV≤200
|
|
430
|
≤0.12
|
≤1.00
|
≤1.25
|
≤0.040
|
≤0.03
|
-
|
16.00/18.00
|
-
|
HB≤183, HRB≤88 HV≤200
|
